SoundDigital SW8 8-Way Automatic/Manual 2-in-1 Switch

The SW-8 is a high-performance 8-channel audio A/B switcher with automatic/manual switching capabilities. It enables one-touch switching of output signals from Group A's 8-channel balanced audio input to Group B's 8-channel input. The internal circuitry features passive/lossless switching with active control architecture. Manual mode supports both digital and analog signals, while power-off A-channel bypass and dual power supply ensure reliability. Multiple SW-8 units can be connected for seamless one-touch switching, maximizing operational safety. This device is ideal for audio systems in studios, main control rooms, and broadcast vans.

Two switching modes

·Automatic switching mode: Selects either an external signal (analog audio) or the first channel of Group A as the detection source (digital/analog compatible, following the input signal pattern). When the input signal falls below a specified threshold for an extended duration, the switch automatically switches channel A to channel B (8 channels switch simultaneously).

·Manual mode: (Digital/analog compatible) When the device is set to manual mode, the A/B signal channels (8 channels each) can be switched with a single button.

Features

·8-channel digital/analog audio A/B switcher

·Adopting passive lossless switching with active control architecture, it provides the most secure switching solution

·The monitoring source can be set to external signals (analog) or internal first-channel signals (digital/analog, following input mode)

·A/B status display, input signal mode display (digital/analog)

·A/B switch auto/manual toggle button

·GPIO interface for remote control and external alarm control

·Automatic alarm/level switching threshold, delay time adjustable via toggle switch

·Control circuit master-slave redundant power supply, channel A bypass in power failure or loss of control
